Unicast Routing
Border Gateway Protocol (BGP) gives information on the path to reach other networks
How to route traffic within an AS?
- Single trust domain
- No policy restrictions on who can determine network topology
- No policy restrictions on which links can be used
- Desire efficient routing → shortest path
- Make best use of the network you have available
Two approaches
Distance vector routing:
- Simple to implement
- Routers only store the distance to each other node: O(n)
- Suffers from slow convergence
Link State routing:
- More complex
- Requires each router to store complete network map:
- Much faster convergence
Slow convergence times make distance vector routing unsuitable for large networks
Distance Vector
The Routing Information Protocol (RIP)
Nodes maintain a vector containing the distance to every other node in network Periodically exchanged with neighbours, eventually every node know distance and next hop to every other node Packets forwarded on shortest path to destination
Not widely used in practice:
- Slow to converge in normal operation
- Count-to-infinity problem makes this worse on failure in networks containing loops
Ex:
Link State
Open Shortest Path First Routing (OSPF)
Nodes know the links to their neighbours, and cost of using those links – link state information
- Flood this information throughout the network on startup, and whenever a link is added or removed
- Send address of node sending the update, the list of directly connected neighbours and costs for link usage, and message sequence number
- Sequence numbers prevent loops
- Each node then directly calculates shortest path to every other node, uses as routing table
Flooding link state data from all nodes ensures all nodes know the entire topology
- Each node uses Dijkstra’s shortest-path algorithm to calculate optimal route to every other node
- Optimal is assumed to be the shortest path, by cost
Core Challenges
How to rapidly recover from link failures?
- Construction work surprisingly good at breaking network cables; trawlers do similar damage to undersea cables
- Good network designs have multiple paths from source to destination
- Must quickly notice failure and switch to backup path
- If the link is used for telephony or video streaming, this must happen in <1/60th of a second else it interrupts the speech or video playout
- Fast failover – pre-calculate alternative paths to allow rapid switchover
How do we load balance over many paths?
- Equal Cost Multipath Routing - if two paths with the same cost, alternate traffic between them
- Care Needed: TCP uses a triple duplicate ACK to signal loss so is insensitive to small amount of packet re-ordering, but treats large amounts of reordering as loss and slows down
- RTP applications don’t care about order, as long as packets arrive before deadline
